AD8033_ADI00004: operational amplifier test

part name: AD8033_ADI00004
description: Very Low Cost High-Speed FASTFET Op Amp
documentation: http://www.analog.com/static/imported-files/data_sheets/AD8033_8034.pdf
model name: AD8033
library file: AD8033.cir

input and output voltage graph
Input and output voltage of an non-inverting amplifier with amplification factor of 2.
UR voltage graph
Transfer function of an AC non-inverting amplifier.

Test logging messages

testlibrary.pyc creating netlist:  gnetlist -g spice-sdb -l scripts/geda-parts.scm -o model_tests/adi/opamps/AD8033_ADI00004/ng21/ac_amplifier.net model_tests/adi/opamps/AD8033_ADI00004/ng21/ac_amplifier.sch
Using SPICE backend by SDB -- Version of 4.28.2007
schematic-type = normal schematic
Command line passed = gnetlist -g spice-sdb -l scripts/geda-parts.scm -o model_tests/adi/opamps/AD8033_ADI00004/ng21/ac_amplifier.net model_tests/adi/opamps/AD8033_ADI00004/ng21/ac_amplifier.sch
Loading schematic [/home/werner/oss/geda/spicelib/model_tests/adi/opamps/AD8033_ADI00004/ng21/ac_amplifier.sch]
WARNING: Found a placeholder/missing component, are you missing a symbol file? [AD8033_ADI00004]

testlibrary.pyc netlist creation was successful
testlibrary.pyc running simulation:  cd model_tests/adi/opamps/AD8033_ADI00004/ng21 ; ngspice -r X -b simulate.ngspice



Circuit: *

Doing analysis at TEMP = 27.000000 and TNOM = 27.000000


No. of Data Rows : 201
Doing analysis at TEMP = 27.000000 and TNOM = 27.000000


No. of Data Rows : 201
Doing analysis at TEMP = 27.000000 and TNOM = 27.000000

elapsed time since last call: 0.015 seconds.

Total elapsed time: 0.015 seconds.

Total DRAM available = 5983.023438 MB.
DRAM currently available = 1632.265625 MB.
Total ngspice program size = 19.761719 MB.
Resident set size = 935.000 kB.
Shared ngspice pages = 681.000 kB.
Text (code) pages = 1.840820 MB.
Stack = 0 bytes.
Library pages = 5.968750 MB.


testlibrary.pyc simulation run was successful
testlibrary.pyc testing and plotting
output voltage is not a function of input voltage
Circuit does not acheive correct amplification
testlibrary.pyc testing or plotting failed
testlibrary.pyc plotting function died:
cannot convert float infinity to integer
